DRHP15A24BJ1NA
Models
Warranty
No one stands behind their brand like we do. Durastar offers durable airflow during even the harshest heating and cooling conditions. In addition, our warranty provides maximum coverage for total peace of mind.
Extended warranty options are available for both parts and labor. Talk to your contractor for more information.
Learn MoreExplore tax credits and rebatesDRHP15A24BJ1NA Features
- HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area.
- Not all Durastar products may be available in all areas currently. See your local Durastar distributor for details.
- Composite base pan dAMPens sound, secures wire grille and eliminates corrosion.
- Improved Tubing design reduces vibration and stress making unit quieter and reducing opportunity for leaks
- Wire grille provides coil protection, enhances cabinet strength and rigidity
- Optimized defrost characteristics provides better home comfort
- Powder coat paint finish for a long lasting professional finish
- Optimized reversing valve sizing improves shifting performance for quieter unit operation and increased life of the system
- Enhanced mufflers help to dissipate vibration energy
- Sound abating feature added to the scroll compressor significantly reduces noise when system transitions in and out of defrost mode
DRHP15A24BJ1NA
- AMP: 25
- Application: Residential
- Auto Switching Heat/Cool?: No
- BTU: 24000
- BTU Cooling Rating: 24000 Btu/h
- Color/Finish Category: Greys
- Color/Finish Name: Iron Ore Grey
- Communicating: Non-Communicating
- Compressor Type: Scroll
- Decibel Rating (dB): 76.4 dB
- EER: 13
- Energy Star Compliant: Yes
- Green Product: Yes,Energy Star
- Height: 25 in
- HSPF: 9
- Length: 29-3/4 in
- Liquid Line (OD): 3/8 in
- Max CFM: 2478 cfm
- MBH: 24
- Phase: Single Phase
- Refrigerant: R-410A
- SEER: 15.5
- Sound Blanket: No
- Specifications - CSA Certified: No
- Specifications - ETL Listed: No
- Specifications - UL Listed: Yes
- Suction Line (OD): 3/4 in
- Vent or Ducted or Ductless: Ducted
- Volts: 208/230V
- Weight: 152 lb
- Width: 29-3/4 in
Frequently Asked questions
What’s more important, HSPF or SEER?
If you live in an area where winters are mild, then pay extra attention to the SEER rating. Conversely, if you live in the north where winters are more extreme, then the HSPF value is more important.
What are the main differences between a heat pump and a mini-split heat pump (otherwise known as a ductless heat pump)?
Generally, heat pumps are integrated into your home’s central heating and cooling system. That means the heat it provides travels through ducts into various rooms throughout your home. Alternatively, mini-split heat pumps, or ductless heat pumps, distribute heat directly into the room where they are installed.
What is HSPF2?
HSPF2 stands for Heating Seasonal Performance Factor 2. HSPF2 is a standardized rating used by all heat pump manufacturers to compare energy efficiencies between heat pumps. The higher the HSPF2, the more efficient the system operates during cold seasons.
How to talk to your contractor
Learn how to talk the talk with a few of our top tips. We cover important questions to ask your HVAC contractor, common mistakes when buying a new system, and more.
