208-240V ECM Air Handlers - Two-Stage Constant Torque
Increase efficiency with Durastar’s thoughtfully designed and highly tested HVAC equipment.
Durastar’s 208-240V ECM air handlers feature a 2-stage constant torque motor. With dual stages, customers experience increased energy efficiency as well as evenly distributed temperature control. All of our air handlers, including our variable-speed three-stage CFM and 115V ECM two-stage units, have a durable steel cabinet and reinforced foil-faced insulation in order to reduce operating noise. Additional features include the aluminum indoor coil design which is constructed with aluminum fins that are bonded to internally grooved tubing providing increased corrosion resistance. With multiple configurations and a compact design, 208-240V ECM air handlers can be installed for upflow, downflow, horizontal-left, and horizontal-right applications. Discuss key specifications and considerations when purchasing an air handler with your HVAC contractor.
Models
Warranty
No one stands behind their brand like we do. Durastar offers durable airflow during even the harshest heating and cooling conditions. In addition, our warranty provides maximum coverage for total peace of mind.
Extended warranty options are available for both parts and labor. Talk to your contractor for more information.
Learn MoreExplore tax credits and rebates208-240V ECM Air Handlers - Two-Stage Constant Torque Features
- HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area.
- Not all Durastar products may be available in all areas currently. See your local Durastar distributor for details.
- Sturdy steel cabinet with one inch of foil faced insulation for quiet and efficient comfort.
- Aluminum Indoor Coil Design: Constructed of aluminum fins bonded to internally grooved aluminum tubing and are more corrosion resistant
- Versatile 4-Way Convertible Compact Design: Allows for upflow, downflow, horizontal left, and horizontal right applications even in the smallest of spaces
- Less than 2% Cabinet Air Leakage at 1-inch H2O: When tested in accordance with ASHRAE Standard 193
- Coils are tested at the factory with an extensive refrigerant leak check
DRAH2TA2417ASTNNJ
- BTU: 24000
- BTU Cooling Rating: 24,000 Btu/h
- Blower Type: Multispeed
- Coil Type: N
- Communicating: Non-Communicating
- Configuration: Multi-Position
- Fan Speeds: 5
- Height: 42-1/2 in
- Liquid Line (OD): 3/8 in
- Material: Steel
- Max CFM: 900 cfm
- MBH: 24
- Phase: Single Phase
- Power Source: Electric
- Refrigerant: R-410A
- Specifications - UL Listed: Yes
- Stages: Two
- Style Name: DRAH2TA
- Suction Line (OD): 3/4 in
- Tonnage: 2 Ton
- Type: DRAH2TA2417ASTNNJ
- Volts: 208/230V
- Weight: 92 lb
- Width: 17-1/2 in
Frequently Asked questions
Is an air handler or furnace better?
Both Durastar’s furnaces and air handlers offer dependable options for distributing even airflow throughout your home. When selecting between the two, consider your location and climate. For areas with long warm seasons, an air handler will likely be more energy-efficient, however, we recommend discussing your options with a licensed contractor to ensure the best combinations of HVAC products for your home.
What does variable speed mean?
Variable speed air handlers operate at the lowest possible speed to achieve your desired indoor temperature. This results in increased energy efficiency. Variable speed units are also quieter than standard units.
Is a two-stage air handler more efficient than a single-stage air handler?
Yes, when paired with a two-stage outdoor unit, both units will operate on low capacity during milder days, requiring less energy; and switch to full capacity and power when needed.
